SPECIFICATIONS

Display Screen Size: 5"
Display Screen Element: Color TFT LCD
Resolution: 980 Lines H x 234 Lines V
Dot Pitch: 0.136 W x 0.416 H
Color Configuration: RGB Strip
Video System FH: 15,750 KHz NTSC
Video System FV: 60 Hz NTSC
Video System FC: 3.58 MHz NTSC
Input Video Signal: 1Vp-p 75 Ohms
Stereo Audio Input: 2 Vp-p 2K Ohms
Speaker: 0.1W/8 Ohms x 2
Power Supply: DC+12V
Consumption: 270mA
Operating Temperature: -10?to 45°C
Storage Temperature: -20?to 60°C
Humidity Max.: 85% RH
Dimensions: W165mm, H170mm, D130mm
Weight: 554g
